Industrial Woven Wire Cloth
The stainless steel mesh comes in three different types, which are fine, medium, and coarse. Most manufacturers use stainless steel as their most preferred woven screen to make different products.
Stainless steel wire mesh is a crucial component in various industries. There is virtually nowhere you can go without finding stainless steel wire mesh used:
>Marine applications
>Filtration equipment
>Sizing applications
>Faucet Screen
>Insect Screen
>CRT Screen
>Light fixture
>Supporting filter media
>Decorative purposes
This is quite simply because of the many benefits that stainless steel mesh commands, the benefits are:
>Mitigates Rust
>Offers Durability
>Ready to Use
>Unlimited Customization
The common size is
Mesh | Wire Diameter | Impurity Particle Size | Mesh | Wire Diameter | Impurity Particle Size |
10mesh | 0.55mm | 2000um | 60mesh | 0.15mm | 273um |
12 | 0.50 | 1600 | 80 | 0.12 | 198 |
14 | 0.45 | 1350 | 100 | 0.10 | 150 |
16 | 0.40 | 1200 | 120 | 0.08 | 132 |
18 | 0.35 | 1000 | 150 | 0.065 | 100 |
20 | 0.30 | 970 | 180 | 0.053 | 88 |
30 | 0.25 | 600 | 200 | 0.023 | 74 |
40 | 0.21 | 425 | 250 | 0.04 | 60 |
50 | 0.19 | 318 | 300 | 0.035 | 49 |
And more material is available, Oil Proof Mesh, Ni-Cr Alloy Wire Mesh 2080, Monel 400 Wire Mesh, Titanium Wire Mesh, FE CR AL Wire Mesh, Nickle Wire Mesh N4,N6, Inconel alloy wire mesh,Molybdenum Mesh etc.
